ZEPRO ZT 200/250 Mk2

LAADKLEPPEN

Onze middelzware tot zware schuiflift, met enkelvoudig inklapbaar platform, speciaal ontworpen voor installatie onder opleggers. Hefcapaciteit van 2000 en 2500 kg.
The ZT Mk2 features a powder-painted, high-strength steel frame and platforms in different sizes, and options.

Robust and sturdy design with corrosion-protected cylinders and the new solid state control system makes this the perfect choice for all heavy trucks.

Smooth movement is enabled by a sliding system that has a hydraulic motor driving two sprockets which rotate and run under the slide profiles guided by simple, sturdy chains. Operation noise is kept to a minimum with a built-in hydraulic unit that also houses sensitive components.

A slimline version designed to maximise ground clearance is also available.

All capacity versions offer spring-assisted, folding aluminium platforms to ensure low weight and ease of use when operating manually.

Standaard en optionele kenmerken

Modelspecificaties

Hefcapaciteit (kg)
Platform Types
Max platformlengte (mm)
Max platformbreedte (mm)
Hoogte verlichting (mm)
ZEPRO ZT 200-135ZEPRO ZT 200-155ZEPRO ZT 250-135ZEPRO ZT 250-155
2000200025002500
Alu AluAlu AluAlu AluAlu Alu
1965196519651965
2400240024002400
1330151013301510
