Hiab is the world's leading provider of on-road load handling equipment, intelligent services, smart and connected solutions.

Hiab - We keep everyday life moving

HIAB X-HiPro 418

PagePreview

Service and Support

Request a quote

Some jobs simply demand more. And when they do, you need your time for moving the load – not your truck. The HIAB X-HiPro 418 has continuous slewing, so it provides 360o of continuous freedom. But it also delivers powerful lifts close to the truck, thanks to its purpose-built short-boom design and advanced, capacity-optimising features. With an outreach of 17.5 m and weighing just 4375 kg, the HIAB X-HiPro 418 is ideal for non-stop demands.

X-HIPRO 418EP-2

X-HIPRO 418EP-3

X-HIPRO 418EP-4

X-HIPRO 418EP-5

#/categories/category[@name='productfinderhiab']/description#

ProductFinderHIAB

HIAB HiPro is the most advanced remote control system in the industry. With a high flow of oil that allows many simultaneous movements, it ensures the highest speed and precision – for the greatest productivity.

HIAB HiPro has Automatic Speed Control (ASC), which increases capacity without stopping or any action from the operator.
Pump Flow Distribution (PFD) distributes the oil evenly in proportion to control movements, ensuring supersmooth operation without sudden load accelerations.

USP_634599

Image_635217

HIAB HiPro

LSS automatically compensates for unintentionally excessive lever moment in vertical operations. This makes crane operation faster and smoother and helps protect the cargo, the vehicle and the work environment in the vicinity of the crane against potential damage.

USP_652652

Load Stability System for vertical movements (LSS-V)

HIAB loader cranes are built to perform, with strong materials and a quality of workmanship no other supplier can match. And because we build them with care, we stand behind them with confidence. Today all HIAB cranes come with a two-year standard warranty that applies to all components. Not only does it cover the parts you expect, it also covers the following wear parts:
• Painting • Seals (both internal and external) • Flexible hoses

USP_634603

Image_635221

Two-year warranty

With continous slewing you will get a faster load cycle times which increases productivity. Operators have in 360°of total freedom to move the crane where needed, avoiding unnecessary backtracking.
You also get everything in easy reach which easier and safer lifting. Operators can always choose the best path for lifting from A to B, avoiding unnecessary and potentially unsafe stops. Another benefit is that you get a purpose-built design with a optimised perform. Like other big cranes, HIAB big cranes with continuous slewing are specifically built for high precision at long outreach (long-boom applications) or more lifting power close to the truck (short-boom applications).

USP_668733

Film_671654

Continuous Slewing - Animation

Continuous Slewing

ASC gives a step less increase in lifting capacity of up to 10%, all in one smooth, continuous motion. This feature, unique to Hiab, engages automatically, which means that the operator does not feel or notice a thing. The function activates as you reach the regular capacity limit, meaning that you can still lift the load where other cranes would have come to a complete stop. To compensate for the capacity boost, the speed of the inner and outer boom is slightly reduced. Capacity ceiling, safety and efficiency are significantly increased by this feature.

USP_652656

ASC – Automatic Speed Control

Hiab’s unique and patented Automatic Duty Control (ADC) function is the only fully automatic system of its type on the market. It can boost your crane’s listed capacity in suspended load applications by 10% without imposing additional stress or fatigue on the steel structure. This helps to reduce maintenance over the lifetime of the crane. If your crane detects upward pressure on the boom tip – for example, when digging or auguring – the capacity will automatically return to normal level. With ADC you can safely perform lifts that would otherwise exceed the crane’s capacity and you can continue to work without interruption when a high-capacity lift is needed. ADC increases the versatility of the crane and makes it more serviceable.

USP_652657

ADC – Automatic Duty Control

nDurance - Protect your investment
* Uphold long-term performance with effective anti-corrosive protection
* High-Tech paint process based on nano-technology and e-coating
* Keeping your crane viisually appealing year after year
nDurance is a technologically advanced and environmentally sound pre-treatment and paint process, based on nano technology combined with state-of-the-art e-coating and powder painting.

Read More about nDurance: https://www.hiab.com/en/global/ndurance

USP_657325

Film_646329

nDurance Video

nDurance

VSLPLUS is a safety system that maximises the crane capacity by calculating the stability according to the position of the stabiliser legs and the total weight of the truck.

USP_635222

Film_635224

HIAB VSL PLUS

Film_1046825

HIAB VSL Animation

VSL PLUS (Variable Stability Logic Plus)

Semi-Automatic Folding (SAF) is a feature that allows the operator to fold and unfold the boom system in one single sequence, using only one lever. SAF is available both for XSDrive 6 levers and for XSDrive joystick controllers.

The folding and unfolding is operated to/from normal folded position (Napoleon folding). It is one, fixed sequence of movements. The operator decides the speed of the movements adjusting the lever stroke.

USP_674442

Film_674452

SEMI AUTOMATIC FOLDING (SAF)

Semi-Automatic Folding (SAF)

Our equipment comes connectivity enabled. Connectivity, in combination with our connected services, allows you to be in constant contact with equipment, assets and people to enhance the productivity, efficiency and safety of your business.

USP_1083677

Connectivity

Hiab Corporate

English

Australia

Austria

Deutsch

Belgium

Dutch

Française

Brazil

Português

China

中文

Czech Republic

Čeština

Denmark

Dansk

Finland

Suomi

France

Germany

India

Italy

Italiano

Japan

日本語

Latin America

Español

Netherlands

Norway

Norsk

Poland

Polski

Singapore

Spain

Sweden

Svenska

Ukraine

Yкраїнська

United Kingdom

United States

BrandsLink

Fill out the form below and someone will be in touch with you soon.

en-IN

cs-CZ

en-SG

en-CA

fr-CA

Hiab main contact #form

How can we help you?

General inquiries

contact page 24px 1.svg

<p>Use the&nbsp;<strong><a href="/en-gb/dealerservice-point-map">Hiab Locator</a></strong>&nbsp;to find more relevant dealers and service points.</p>

Dealer/Service point map

No Results. Zoom out to see more dealers or service points.

Find a dealer or service point

#/categories/category[@name='map']/description#

Hiab webshop

Footer Block

Hiab locator

Contact Us

Product finder

About loader cranes

Installations

Loader crane accessories

Maintenance contracts

HiPerform smart solutions

Spare parts

Warranty

HIAB wspr - Electric Hybrid Crane Solutions

Electric solutions

<p>Discover HIAB loader cranes for track maintenance all the way up to recovery models for an efficient railway network infrastructure.</p>

Railway solutions

Loader cranes

About forestry cranes

Forestry crane accessories

HiSkill training simulator

Forestry cranes

About recycling cranes

Recycling crane accessories

<p><span style="font-weight: 400;">Covers the parts you expect, and more</span></p>

JONSERED  warranty

Recycling cranes

Products

Brands

About Hooklifts & Skiploaders

Service and Warranty

HiVision

HiConnect

Industry and Applications

Hooklifts & Skiploaders

About truck mounted forklifts

MOFFETT eSeries NX

Truck Mounted Forklifts

Industry and Segments

ZEPRO

Original Parts and Service

Discover DEL Solar Charger

Tail lifts

Buy accessories from Webshop

Find an accessory in the product finder

Find a dealer

Accessories

Tail lift accessories

Energy efficient accessories

Find a service center

Maintenance

How can HiPerform smart solutions prevent costly mistakes?

Lifecycle services

Contact forms

General inquiries

Find contact

Hiab United Kingdom

Locate a dealer

Locate dealers

Locate a service point

Contact us

About Us

Industries

Sustainability

Settings

<ul>
<li><strong>Modify search test - </strong>Check the spelling, expand abbreviations, use fewer or more general keywords.</li>
<li><strong>Browse instead - </strong>Try the navigational options in the menu at the top left of the page.</li>
<li><strong>Are you looking for spare parts? - </strong>Contact your <a href="/en-gb/dealerservice-point-map?zoom=10&amp;effer=false&amp;hiab=false&amp;jonsered=false&amp;loglift=false&amp;moffett=false&amp;multilift=false&amp;zepro=false&amp;installation=false&amp;mobileservice=false&amp;service=false&amp;spareparts=false&amp;training=false&amp;warranties=false&amp;forestryCranes=false&amp;hookliftsAndSkiploaders=false&amp;loaderCranes=false&amp;recyclingCranes=false&amp;tailLifts=false&amp;truckMountedForklifts=false&amp;dealers=true&amp;services=false">local dealer</a> or go to our <a href="https://webshop.hiab.com/en/?utm_source=permanent_links&amp;utm_medium=hiab_com&amp;utm_campaign=links&amp;utm_content=top_menu" target="_blank" rel="noopener">Webshop</a></li>
<li><strong>Are you looking for prices? -</strong> Contact your <a href="/en-gb/dealerservice-point-map?zoom=10&amp;effer=false&amp;hiab=false&amp;jonsered=false&amp;loglift=false&amp;moffett=false&amp;multilift=false&amp;zepro=false&amp;installation=false&amp;mobileservice=false&amp;service=false&amp;spareparts=false&amp;training=false&amp;warranties=false&amp;forestryCranes=false&amp;hookliftsAndSkiploaders=false&amp;loaderCranes=false&amp;recyclingCranes=false&amp;tailLifts=false&amp;truckMountedForklifts=false&amp;dealers=true&amp;services=false">local dealer</a> for product prices</li>
<li><strong>Contact us - </strong>Find your <a href="/en-gb/dealerservice-point-map?zoom=10&amp;effer=false&amp;hiab=false&amp;jonsered=false&amp;loglift=false&amp;moffett=false&amp;multilift=false&amp;zepro=false&amp;installation=false&amp;mobileservice=false&amp;service=false&amp;spareparts=false&amp;training=false&amp;warranties=false&amp;forestryCranes=false&amp;hookliftsAndSkiploaders=false&amp;loaderCranes=false&amp;recyclingCranes=false&amp;tailLifts=false&amp;truckMountedForklifts=false&amp;dealers=true&amp;services=false">local dealer</a> or <a href="/en-gb/dealerservice-point-map?zoom=10&amp;effer=false&amp;hiab=false&amp;jonsered=false&amp;loglift=false&amp;moffett=false&amp;multilift=false&amp;zepro=false&amp;installation=false&amp;mobileservice=false&amp;service=false&amp;spareparts=false&amp;training=false&amp;warranties=false&amp;forestryCranes=false&amp;hookliftsAndSkiploaders=false&amp;loaderCranes=false&amp;recyclingCranes=false&amp;tailLifts=false&amp;truckMountedForklifts=false&amp;dealers=false&amp;services=true">Service Point</a> or use our Contact Form by clicking on "Contact Us"</li>
</ul>

User-agent: *
Disallow: */Settings
Disallow: */settings
Disallow: */~/link/
Disallow: /*.dat$
Disallow: /*.aspx$
Disallow: */sandbox/*


<p>If you are<strong class="Typographystyle__BodyStrong-sc-12p52d0-6 gWPfrO">&nbsp;not a dealer</strong> and are looking to purchase <em>spare parts or accessories</em>, please click on the "Find a dealer" button</p>

The webshop is for dealers only

X-HIPRO 418EP-2	X-HIPRO 418EP-3	X-HIPRO 418EP-4	X-HIPRO 418EP-5
HiPro	HiPro	HiPro	HiPro
8	10.3	12.7	15.1
389	382	376	371
3772	3992	4207	4375

HIAB X-HiPro 418
